| Series |
|
|
|
|
|
|
|
|
|
|
|
|
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Operating Temperature | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -65℃～+125℃ |
| Vibration | 10Hz～2000Hz 196m/s2 | 10Hz～2000Hz 196m/s² | 10Hz～2000Hz 196m/s² | 10Hz～2000Hz 196m/s2 | 10Hz～2000Hz 196m/s2 | 10Hz～2000Hz 196m/s² | 10Hz～2000Hz 196m/s² | 10Hz～2000Hz 196m/s2 | 10Hz～2000Hz 196m/s² | 50Hz～2000Hz 150m/s2 | 50Hz～2000Hz 147m/s2 | 10Hz～2000Hz 196m/s2 | 10 Hz to 2000 Hz, 147 m/s², transient interruption ≤ 1 μs |
| Random Vibration | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 23.1 G | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 23.1 G | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 23.1 G | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 23.1 G | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 23.1 G | Power Spectral Density: 0.4 G²/Hz Total Acceleration Root Mean Square (RMS): 23.1 G | - | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 28.4 G" | Power Spectral Density (PSD): 0.4 G²/Hz; Total Acceleration RMS Value: 23.1 G. | - | - | - | - |
| Shock | 980m/s2 6ms | 735m/s² 11ms | 735m/s² 11ms | 735m/s2 11ms | 735m/s² 11ms | 735m/s2 11ms | 735m/s² | 1200m/s2 6ms | 735m/s² 11ms | 1000m/s2 10ms | 735m/s2 11ms | 735m/s2 11ms | 980 m/s², transient interruption ≤ 1 μs |
| Rated Current | 1A | 3A | 3A | 3A | 3A | 3A | 3A | 5A | 3A | 3A | 3A | 3A | 1A（ 0.6） |
| Contact Resistance | ≤ 21mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 20mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤12.5mΩ |
| Insulation Resistance | ≥ 5000MΩ 100VDC | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ 500VDC | ≥ 5000MΩ (500VDC)；≥ 100MΩ under damp heat conditions | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ 500VDC | 5000 MΩ (normal condition), 100 MΩ (humid heat condition) |
| Dielectric Voltage | 250V | 800V | 800V | 800V | 800V | 600V | 800V (ambient temperature) | 1500V DC | 800V | 1000V | 600V | 800V | - |
| Mechanical Life | 200 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles |
| Series |
|
|
|
|
|
|
-
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Operating Temperature | W Class: -65℃～175℃；F Class, K Class: -65℃～+200℃ | -55℃~+175℃ -55℃~+200℃ (Class L, Class A, Class S ) | Class B -65℃+175℃ Class C, Class E, Class F -65℃-+200℃ | Class B -65℃+175℃ Class C, Class E, Class F -65℃-+200℃ | Class B -65℃+175℃ Class F, Class K -65℃-+200℃ | Class J -65℃~+175℃ Class M-65℃ ~+200℃ | Class B-65℃+175℃ Class F, Class K -65℃-+200℃" | -55℃～+125℃ | -55℃～+125℃ -55℃～+175℃（Only for Y17-1604 Specification） | -55℃～+125℃ | -55℃～+125℃ | -55℃～+125℃ | For operating temperatures above 150℃, specify when placing an order; a ""*"" symbol may be added at the top-left corner of the housing part number | (For operating temperature above 150℃, please specify when placing an order.A ""*"" symbol may be added at the top-left corner of the housing number) | -55℃~200℃ | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ -55℃～+200℃ (Specify when placing an order) | -55℃～+125℃ | -60℃～+85℃ |
| Relative Humidity | - | 95% ±4% at 65℃ | 98% at 40℃ | 98% at 40℃ | - | - | - | Relative humidity: 90%–95% at 40℃±2℃ | Relative humidity: 90%–95% at 40℃±2℃ | Relative humidity: 92%–98% at 40℃±2℃ | Relative humidity: 90%–95% at 40℃±2℃ | Relative humidity: 90%–95% at 40℃±2℃ | Relative humidity: 90%–95% at 40℃±2℃ | Relative Humidity: 90%–95% at 40℃±2℃ | 95% at 40℃ | 90%–95% at 40℃±2℃ | 90%–95% at 40℃±2℃ | 90%–95% at 40℃±2℃ | 90%–95% at 40℃±2℃ | 90%–95% at 40℃±2℃ | 90%–95% at 40℃±2℃ | 90%–95% at 40℃±2℃ | 90%–95% at 40℃±2℃ | 90%–95% at 40℃±2℃ | 90%–95% at 40℃±2℃ | 95% at 60℃ | 93% at ±40℃±2℃ | - |
| Vibration | 60g, with temperature cycling and simulated accessories (36 hours) | Acceleration196m/s² | 10Hz～2000Hz Acceleration147m/s² | 100～2000Hz PSD 1G2/Hz | 60 g, with temperature cycling and simulated accessories (3 hours) | 60 g, with temperature cycling and simulated accessories (3 hours) | 10Hz～2000Hz Acceleration294m/s² | 10Hz～50Hz double amplitude2mm 50Hz～2000Hz Acceleration196m/s2 | 10Hz～2000Hz Acceleration98m/s² | 10Hz～2000Hz Acceleration196m/s2 | 10Hz～2000Hz Acceleration196m/s2 | 10Hz～2000Hz Acceleration196m/s² | 10Hz～2000Hz Acceleration196m/s2 | 10Hz～2000Hz acceleration 196m/s² | Frequency10～2000Hz Acceleration196m/s² | 10～2000Hz Acceleration196m/s2 | Frequency10～2000Hz Acceleration196m/s2 | 10～2000Hz Acceleration196m/s² | Frequency10～2000Hz 196m/s² | Frequency10～2000Hz Acceleration196m/s² | - | - | - | - | - | Frequency10～2000Hz Acceleration196m/s² | Frequency10～2000Hz Acceleration196m/s2 | Frequency1～5000Hz 20g |
| Random Vibration | 44.1g rms at high temperature; 49.5g rms at ambient temperature | - | 10Hz～2000Hz Normal Density147m/s² | 100～2000Hz PSD 1G2/Hz | 44.1 g rms at high temperature49.5g rms at ambient temperature | 44.1 g rms at high temperature49.5 g rms at ambient temperature | 100～2000Hz PSD1G²/Hz | Power Spectral Density (PSD): 40 m²/s⁴/HzRoot Mean Square (RMS) Value: 239.1 m/s² | - | Power Spectral Density (PSD): 0.4 g²/HzRoot Mean Square (RMS) Acceleration: 23.1 g | - | - | - | - | Power Spectral Density (PSD): 0.6 g²/HzRoot Mean Square (RMS) Acceleration: 28.4g | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Shock | 3ms half-sine wave, acceleration peak value 300g | Acceleration294m/s² | 3 ms half-sine wave, peak acceleration 300g | 3ms half-sine wave, peak acceleration 300g | 3ms half-sine wave, peak acceleration 300g | 3ms half-sine wave, peak acceleration 300g | 3ms half-sine wave, peak acceleration 300g | Acceleration980m/s2 | Acceleration490m/s² | Acceleration980m/s2 | 490m/s2 ≤1 μs | Acceleration980m/s² | Acceleration980m/s² | acceleration 980m/s² | - | acceleration 980m/s² | acceleration 980m/s² | acceleration 980m/s² | acceleration 980m/s² | acceleration 980m/s² | acceleration 980m/s² | acceleration 980m/s² | acceleration 980m/s² | acceleration 980m/s² | acceleration 980m/s² | Acceleration980m² | Acceleration980m² | - |
| Salt Spray Resistance | Class W: 500h; Class F: 48h; Class K: 1000h | 48h(Class A) 96h(Class L) 500h(Class W) 1000h(Class S) | Class B:500h Class C:96h Class E:1000h Class F:48h | Class B:500h Class C:96h Class E:1000h Class F:48h | Class W: 500h Class F: 48h Class K: 1000h | 2000h | Class W: 500h Class F: 48h Class K: 1000h | - | - | Y27, Y27A, B, C Series: 48 h;Y27F, G, H Series (Aluminum Alloy Housing): 48 h;Naval Brass/Stainless Steel Housing: 1000h | - | Complies with the provisions of 3.6.13 in GJB 1217A-97Test shall be conducted in accordance with Method 4.6.13 | - | - | Aluminum Alloy Housing Surface: 200 h ，Copper Alloy Housing Surface: 500 h ，Stainless Steel Housing Surface: 100 h | - | - | - | - | - | - | - | - | - | Excellent performance in 1000-hour salt spray resistance test | Excellent performance in 1000-hour salt spray resistance test | - | - |
| Sealing Performance | - | - | - | - | The mating connector complies with the low-pressure immersion requirements of MIL-DTL-38999K | The mating connector complies with the low-pressure immersion requirements of MIL-DTL-38999K | The mating connector complies with the low-pressure immersion requirements of MIL-DTL-38999K | 0.2Mpa | - | Rubber Seal Leak Rate ≤ 1 Pa·cm³/s | Receptacle withstands air pressure not less than 196 kPa | - | - | - | - | Dual-End Sealed Receptacle: Pressure Difference 50.7 kPa, Leak Rate ≤ 46 Pa·cm³/s | Dual-End Sealed Receptacle: Pressure Difference 50.7kPa, Leak Rate ≤ 46Pa·cm³/s | - | - | - | - | - | - | - | - | - | - | - |
| Mechanical Life | Mating cycles ≥ 500 | Mating Cycles ≥ 500 | Mating Cycles ≥ 500 | Mating Cycles ≥ 500 | Mating Cycles ≥ 500 | Mating Cycles ≥ 1500 | Mating Cycles ≥ 500 | Mating Cycles ≥ 500 | Mating Cycles ≥ 500 | Mating Cycles ≥ 1000 | Mating Cycles ≥ 1000 | Mating Cycles ≥1000 | Mating Cycles ≥ 500 | Mating Cycles ≥ 500 | Mating Cycles ≥1000 | Mating Cycles ≥1000 | Mating Cycles ≥1000 | Mating Cycles ≥1000 | Mating Cycles ≥ 1000 | Mating Cycles ≥1000 | Mating Cycles ≥1000 | Mating Cycles ≥1000 | Mating Cycles ≥1000 | Mating Cycles ≥1000 | Mating Cycles ≥1000 | Mating Cycles ≥ 1000 | Mating Cycles ≥ 500 | Mating Cycles: ≥ 250Operating Life: 5000 hours |
