Product Designation Code

XTH YMG 16 T  3 K1 P40 X
 ①     ②    ③ ④ ⑤ ⑥ ⑦  ⑧

1—Enterprise Designation of Shenzhen Xuntonghang Technology Co., Ltd.
2—YMG Series Marine Anti-Corrosion Waterproof Electrical Connectors
3—Shell Size: 16, 18, 20, 22, 24, 27, 30, 33, 36, 39
4—Shell Type: T-Plug; F-Square Flange Receptacle
5—Number of Contacts: Refer to YMG Contact Arrangement Diagram
6—Contact Type: Z-Gold-Plated Pin; Ki-Gold-Plated Socket
7—Shell Plating and Structure:
D40-Short Shell, No Thread at Tail, Stainless Steel Passivation (Only for Square Flange Receptacles and Through-Wall Hermetically Sealed Adapters)
P40-With Thread at Tail, Optional Accessories, Stainless Steel Passivation
D1-Short Shell, No Thread at Tail, Aluminum Alloy, Electroless Nickel Plating
P1-With Thread at Tail, Optional Accessories, Aluminum Alloy, Electroless Nickel Plating
8—Key Position: Unmarked-N Key Position; (W)-W Key Position; (X)-X Key Position; (Y)-Y Key Position;
(Z)-Z Key Position
Note:
1 ) .When indicating an electrical connector, the model marking adopts a fractional format. The receptacle marking is written as the numerator, and the plug marking as the denominator (only the shell plating and structural form of the plug may be specified), separated by a slash.
2.The model numbers of plugs and receptacles are directly marked on the products. The electrical connector model number is used for customer ordering, as well as the company's production and operation management.
Examples:
* Receptacle: YMG Series, Shell Size 16, Equipped with 3-contact sockets, Short shell, With thread at tail, Optional accessories, Stainless steel passivation, N Key Position
Model Marking: YMG16F3KiP40
* Plug: YMG Series, Shell Size 16, Equipped with 3-contact pins, With thread at tail, Optional accessories, Stainless steel passivation, N Key Position
Model Marking: YMG16T3Z P40
* Complete Electrical Connector Model: YMG16F3KiP40/P40
