Product Designation Code

XTH Y 27 A III - 20 24 T/Z J/K B M  A Ⅱ B
①    ② ③ ④ ⑤   ⑥ ⑦  ⑧   ⑨  ⑩ ⑪ ⑫⑬ ⑭

1—Enterprise Designation of Shenzhen Xuntonghang Electronic Technology Co., Ltd.
2—Main Designation Code for Circular Electrical Connectors
3—Military Registered Design Serial Number
4—Metric Series: Q, A, B, C, F, G, H (Q may be unmarked; H indicates wire spring socket)
5—Anti-Misinsertion Index Number: I, II, III (I may be unmarked)
6—Shell Size: 08, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30
7—Number of Contact Pairs: See Type Spectrum Description
8—Connector Type: T-Plug; Z-Receptacle
9—Contact Type: J-Pin; K-Socket
10—Cable Exit Configuration: L-Cable Type; B/B1-Square Flange Mounting; B2-Nut Mounting;
B4-Through-Wall Mounting
11—Receptacle Sealing Type: M-Rubber Sealed; P-Non-Sealed (Unmarked)
12—Separation Type (Plug Only): A-Push/Pull Type (May be Unmarked)
13—Cable Boot Accessory Type: No Marking-No Cable Boot Accessory; I-Equipped with Type I;
m-Equipped with Type m; V-Equipped with Type V; X-Equipped with Type X
14—Shell Material Category Code: No Marking-Aluminum Alloy (Nickel Plated); B-Stainless Steel (Passivated); C-Navy Brass (Nickel Plated)
