Product Designation Code

XTH Y  11  X Ⅲ 20 41 Z   J  10 2
①     ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪

1—Enterprise Designation of Shenzhen Xuntonghang Electronic Technology Co., Ltd.
2—Main Designation Code for Circular Electrical Connectors
3—Military Standard Registered Design Serial Number
4—Category Code: X-Potted Type; P-Shielded Potted Type; P1-Electroless Nickel Plated Shielded Potted Type;
S-Copper Shell Electroless Nickel Plated Potted Type; B-Stainless Steel Shell Potted Type
5—Anti-Misinsertion Index Number: I, II, III, IV, V (No Marking for Index I)
6—Shell Size: 08, 10, 12, 14, 16, 18, 20, 22, 24
7—Number of Contact Pairs: 2~61 Contacts
8—Connector Type: T-Plug; Z-Receptacle
9—Contact Type: J-Pin; K-Socket; S-Feedthrough Pin/Socket
10—Receptacle Mounting Method: 10-Square Flange-Mounted; 11-Circular Flange-Mounted; 14-Nut-Fastened Type
11—Cable Exit Configuration: 2-Cable Clamp Type; 3b-Short Potting Type; 4-Angled Cable Exit;
5-Heat Shrink Tubing Type 1; 5a-Heat Shrink Tubing Type 2; 6-Shielded Type
Note: The marking for Receptacle Mounting Method (Item 10) applies only to receptacles and is not marked on plugs.
